Solar PV Cable
Operating Temp: −15°C to 90°C
Voltage: 1100 V AC / 1800 V DC
UV & Ozone Resistant
Meets PV1‑F (TÜV 2PfG‑1169/08.2007)
Colours: Black / Red
Overview
Flexible, UV‑resistant solar cable designed for interconnection of photovoltaic systems. Suitable for indoor/outdoor installations,
within conduits or similar closed systems. Standard pack: 100 m, 200 m, 500 m, 1000 m.
Cable Standards
- Conductor: 99.9% pure electrolytic flexible (Class 5) bare copper or tinned copper
- Insulation: UV‑resistant XLPE
- Outer sheath: UV‑resistant XLPE or UV‑resistant HFFR PVC compound
- Cable standard: Generally meets TÜV 2PfG‑1169/08.2007 PV1‑F
Silent Features
- High flexibility & durability for long life
- Excellent resistance to moisture, abrasion, oil & grease
- Excellent electrical & mechanical properties
- UV & OZONE resistance
- Weather resistant
- Standard packing: 100 m, 200 m, 500 m, 1000 m
- Available colours: Black & Red
Technical Data
Operating temperature: −15 °C to 90 °C · Voltage grade: up to 1100 V (AC) & 1800 V (DC)
Oxygen index to catch fire: > 29.5% · Ignition temperature at 21% O₂: > 250 °C · Visibility during cable burning: < 60%
| Size (sq.mm) |
No./Dia of Strand (mm) |
Min. Insulation Thickness (mm) |
Min. Sheath Thickness (mm) |
Overall Diameter (mm) |
DC Conductor Resistance (Ω/km) |
Current Rating (A) |
Permissible Short Circuit Current 5s (kA) |
| 1.5 | 48/0.20 | 0.5 | 0.5 | 4.1 | 13.7 | 30 | 0.19 |
| 2.5 | 50/0.25 | 0.5 | 1.0 | 4.2 | 8.21 | 41 | 0.32 |
| 4 | 56/0.30 | 0.5 | 1.0 | 4.7 | 5.09 | 55 | 0.50 |
| 6 | 84/0.30 | 0.8 | 1.2 | 5.5 | 3.39 | 70 | 0.76 |
| 10 | 80/0.40 | 1.0 | 1.3 | 6.5 | 1.95 | 98 | 1.26 |
| 16 | 126/0.40 | 1.2 | 1.5 | 8.3 | 1.24 | 132 | 2.00 |
| 25 | 198/0.40 | 1.2 | 1.5 | 11.0 | 0.79 | 176 | 3.15 |
Note: Insulation thickness, sheath thickness and overall dimension given in the table are nominal values.
The number of wires and strand diameter satisfy the requirements of conductor resistance as per IS:8130/1984.
Application
Used primarily for interconnection of various elements of photovoltaic systems such as solar panel arrays.
Suitable for internal & external installation, within unprotected pipes or similar closed systems.
Typical uses: Solar panels, Solar power plants, Solar pump installations.
